vue3+ts项目中使用echarts

1.安装echarts

cnpm install echarts --save-dev

2.代码里直接使用，这里我是封装成一个组件使用

<template>
  <div class="chart" ref="ChartContainer"></div>
</template>

<script>
import * as echarts from 'echarts';
import {ref, onMounted, watch} from 'vue'

export default {
    name: "LineChart",
    setup(props) {
        let chart = null;
        const ChartContainer = ref(null);

        onMounted(() => {
            chart = echarts.init(ChartContainer.value);
            chart.setOption(getChartSetOption());
            window.addEventListener('resize', resizeHandler)
        })

        const resizeHandler = () => {
            if (chart) {
                chart.resize()
            }
        }

        return {
            LineChartContainer,
        }
    }
}

function getChartSetOption() {
  let option = {
    grid: {
      top: '20',
      left: '40',
      right: '20',
      bottom: '30'
    },
    xAxis: {
      type: 'category',
      axisTick: {show: false},
      axisLine: {
        show: true,
        lineStyle: {
          color: "#F2F6FC",
        }
      },
      axisLabel: {
        fontSize: 10,
        color: "#F2F6FC",
      },
      data: ['Mon', 'Tue', 'Wed', 'Thu', 'Fri', 'Sat', 'Sun']
    },
    yAxis: {
      type: 'value',
      axisLabel: {
        fontSize: 10,
        color: "#F2F6FC",
      },
      splitLine: {
        show: true,
        lineStyle: {
          color: "rgba(255,255,255,0.1)",
          width: 1,
        },
      },
    },
    series: [
      {
        data: [150, 230, 224, 218, 135, 147, 260],
        type: 'line',
        color: 'rgb(2, 205, 230)',
        symbol: 'circle',
        symbolSize: 8,
      }
    ]
  }
  return option;
}
</script>

<style scoped lang="scss">
.chart {
  width: 100%;
  height: 100%;
}
</style>
